Asphalt Snow Melting Heating Cable & Mat

Name: Asphalt Snow Melting Heating Cable & Mat
Brand: WIPE hotwire

Overview

WIPE hotwire Asphalt Snow Melting Heating Cable and Mat is engineered for permanent installation in asphalt surfaces. Built with twin ETFE-insulated conductors, an XLPE inner jacket, and a high-temperature PVC outer jacket, it delivers sustained, high-output snow-melting performance across roads, car parks, and commercial forecourts.

Region

Features & Specifications

Click a tab to view the key features or the full construction and technical specifications.

Twin solid/multi-strand ETFE insulated heating conductors, 0.25 inch diameter, 0.012 inch insulation thickness
Polyester-laminated aluminium foil with drain wire and ATC braid shielding
XLPE inner jacket 0.024 inch thickness, high-temperature PVC outer jacket
12.5 W/ft linear output, available in 120V, 208V, 240V, 277V and 347V, 60Hz
Glass fiber/nylon mesh carrier, sticky and non-sticky mat variants
1.64 ft mesh width, 50 W/sq.ft heat density, 3-inch cable spacing
Solid/multi-strand tinned copper cold tail, AWG 18 to 14, ETFE insulation
Cold tail length 10 to 20 ft., separate and integrated connection types

Conductor	Twin solid/multi-strand ETFE insulated, 0.25 inch diameter
Shielding	Polyester-laminated aluminium foil with drain wire and ATC braid
Inner Jacket	XLPE, 0.024 inch thickness
Outer Jacket	High-temperature PVC
Linear Wattage	12.5 W/ft
Voltage	120V, 208V, 240V, 277V, 347V, 60Hz
Carrier	Glass fiber/nylon mesh, sticky and non-sticky variants
Mesh Width	1.64 ft
Heat Density	50 W/sq.ft
Cable Spacing	3 inch
Cold Tail	AWG 18 to 14, ETFE insulation, 10 to 20 ft.

Heating conductor	Twin solid/multi-strand conductors (both heating)
Insulation	PTFE
Shielding	Polyester laminated aluminium foil with drain wire
Inner jacket	XLPE
Outer jacket	High temperature PVC
Cable diameter	8.0 mm approx.
Linear wattage	30 W/m
Supply voltage	230V, 50 Hz
Cold tail conductor	Solid/multi-strand tinned copper (AWG 18 & 16)
Cold tail insulation	XLPE
Cold tail shielding	Aluminium foil with drain wire
Cold tail outer jacket	High temperature PVC (thickness 30 Mil)
Cold tail length	3.5 m
Mat carrier	FG mesh, nylon mesh
Mesh type	Sticky, non-sticky, cross filament tape
Mesh width	0.5 m
Heat density	300 W/m²
Cable spacing	100 mm

Applications

Snow melting in asphalt roads and parking areas
Commercial forecourts and large outdoor paved areas

Certifications & Approvals

UL 10086

UL 2464

UL 515

IEEE 515.1

CSA C22.2

CCN: KOBQ/KOBQ/7

Related Products

Electric Underfloor Heating Snow Melting Heating Cable & Mat Effective snow and ice removal across outdoor and paved surfaces. View

Electric Underfloor Heating Constant Wattage Heating Cable High-density constant-wattage cable for roof, gutter and pipe heating. View

Electric Underfloor Heating Earth-Soil Heating System Ground and soil heating for frost-free, all-season outdoor surfaces. View

Frequently Asked Questions

What is an asphalt snow-melting heating cable and mat?

An asphalt snow-melting heating cable and mat is designed for permanent installation within asphalt surfaces to melt snow and ice across roads, parking areas, and other paved surfaces.

Where can asphalt snow-melting heating cables and mats be used?

WIPE hotwire asphalt snow-melting heating systems are designed for roads, driveways, parking lots, and other outdoor paved surfaces requiring snow and ice removal.

What makes the asphalt snow-melting heating cable suitable for asphalt installation?

The asphalt snow-melting cable features ETFE-insulated conductors, an XLPE inner jacket, and a high-temperature PVC outer jacket, making it engineered for permanent installation within asphalt surfaces.

What is the output and voltage range of the asphalt snow-melting heating cable?

WIPE hotwire's asphalt snow-melting heating cable provides a linear output of 12.5 W/ft and is available in 120V, 208V, 240V, 277V, and 347V configurations at 60 Hz.

What are the key features of the asphalt snow-melting heating mat?

The asphalt snow-melting heating mat is available in sticky and non-sticky variants, with a 1.64 ft mesh width, 50 W/sq.ft heat density, and 3-inch cable spacing.

WIPE hotwire Asphalt Snow Melting Heating Cable and Mat is engineered to deliver reliable, high-output snow and ice removal for asphalt roads, parking areas, commercial forecourts, and other high-traffic outdoor surfaces. Designed for permanent embedding within asphalt, our asphalt snow melting heating cable systems provide consistent heat distribution to prevent snow and ice accumulation, improving safety, accessibility, and operational continuity during harsh winter conditions.

Manufactured with twin ETFE-insulated heating conductors, a durable XLPE inner jacket, a high-temperature PVC outer jacket, and advanced aluminium foil shielding with ATC braid, WIPE hotwire asphalt snow melting cables are built to withstand demanding environmental conditions while delivering long-term performance. Available in multiple voltage options with high heat density and uniform cable spacing, our snow melting heating mats and cable systems are suitable for roads, driveways, parking lots, loading bays, and large paved areas requiring dependable outdoor heating solutions.

As a trusted manufacturer of electric snow melting systems, WIPE hotwire partners with OEMs, EPC contractors, infrastructure developers, and commercial project consultants to deliver application-specific asphalt snow melting systems for permanent outdoor installations. Whether you're designing a heated asphalt driveway, specifying a snow melting cable for parking lots, or implementing a large-scale road snow melting system, our engineering expertise and precision manufacturing ensure reliable performance, reduced winter maintenance, and safer outdoor environments.
